Product features：
The 2835 LED is a low-power SMD LED with 0.1W and 0.2W. Because its size is: 3.5mm(width) x 2.8mm(height).
Fixed in accordance with the SMD LED size naming method, named 2835 SMD LED.
The main parameters:
Model | Color | Temperature(K) | Lumen | Power | Forward voltage | (mA) Current | CRI |
GW-2835SMD LED（Single chip） | White | 2800-7000 | 24-26 | 0.2w | 3.0-3.3 | 60 | 70，80，90 |
White | 2800-7000 | 26-28 | 0.2w | 2.8-3.2 | 60 | 70，80，90 | |
White | 2800-7000 | 28-30 | 0.2w | 2.8-3.2 | 60 | 70，80，90 | |
White | 2800-7000 | 30-32 | 0.2w | 2.8-3.2 | 60 | 70，80，90 | |
White | 2800-7000 | 32-34 | 0.2w | 2.8-3.2 | 60 | 70，80，90 | |
GW-2835SMD LED（Single chip） | White | 2800-7000 | 50-60 | 0.5W | 3.0-3.3 | 150 | 70，80，90 |
White | 2800-7000 | 60-65 | 0.5W | 2.8-3.2 | 150 | 70，80，90 | |
White | 2800-7000 | 65-70 | 0.5W | 2.8-3.2 | 150 | 70，80，90 | |
GW-2835SMD LED（Single chip） | White | 2800-7000 | 35-40 | 0.5W | 9-9.5 | 30 | 70，80，90 |
White | 2800-7000 | 65-70 | 0.5W | 18-19 | 30 | 70，80，90 | |
GW-2835SMD LED（Twin chips in series） | White | 2800-7000 | 70-80 | 1W | 6.0-6.2 | 100 | 70，80，90 |
White | 2800-7000 | 80-90 | 1W | 6.0-6.2 | 100 | 70，80，90 | |
White | 2800-7000 | 90-100 | 1W | 6.0-6.2 | 100 | 70，80，90 | |
GW-2835SMD LED（Three chips in series） | White | 2800-7000 | 110-120 | 1W | 9-9.5 | 100 | 70，80，90 |
White | 2800-7000 | 120-130 | 1W | 9-9.5 | 100 | 70，80，90 | |
White | 2800-7000 | 130-140 | 1W | 9-9.5 | 100 | 70，80，90 | |
White | 2800-7000 | 140-150 | 1W | 9-9.5 | 100 | 70，80，90 |
applications：
Application range Of 2835SMD LED:
Applicable industry: fluorescent LED tube, panel lamp, bulb lamp, soft strip, Rigid strip
Applicable equipment: stage lighting equipment, lighting equipment, LED maintenance equipment
Application: high-end exclusive stores, shopping malls, entertainment places, bars, cafes, hotels, guesthouses
Use: medium and high - grade exclusive store, shopping malls, entertainment places, bars, cafes, hotels, guesthouses
Company Information
About Us
Our Advantages
--12 Years Professional Experience in LED Lighting Design.
--Strict Quality Control System and Powerful OEM Capacity from raw materials to finished products.
--Perfect customer service system, customer benefit first forever.
--Pursue Long Term Cooperation, strive for Win-win.
Packaging & Shipping
Our Service
--If you have any questions, please feel free to contact us. We will response within 24 hours.
--Design charge is always free.
FAQ
Q1: What’s the MOQ?
A1: 10pcs/20pcs/50pcs. Sample request is acceptable.
Q2: What’s the lead time?
A2: Based on the quantity of the order.
Q3: Is it ok to make our own brand name?
A3: That’s fine to make your brand name. OEM&ODM is available.
Q4: What are the payment terms?
A4: T/T, Western Union, L/C.
Q5: Where is your loading port?
A5: Guangdong, Ningbo, Shanghai. According to customer’s requirements.
